Gate Knife Valve Φ 200

Product Code: Van Dao Fi 200

Price: 2,750,000 VND
Order

1. Product Information:

GATE KNIFE VALVE Φ 200 SPECIFICATION
Valve handle and disc	Inox 304
Valve body	HDPE sheet, thickness 40mm
Double flange	Φ 200mm
Height without pulling up	46 cm
Height with pulling up	56 cm
Width	17 cm
Weight	3.5kg
Made in	Aqua Mina
Warranty	2 years

Gate knife valve produced by Aqua Mina Co. Ltd

2. What is a Knife Gate Valve?

Knife Gate Valve is a type of valve widely used in various fields for transporting liquids, viscous substances, solids, and powders. Knife Gate Valves are utilized in water supply and drainage systems, firefighting systems, and production lines in industrial areas. Additionally, they find special applications in shrimp and fish farming, facilitating the efficient transfer of shrimp and fish without compromising their health.

Distinguishing itself from PVC ball valves, the Knife Gate Valve features a vertical handwheel design, saving space and proving suitable for narrow locations. It is particularly effective in production lines requiring the smooth flow of fluids, ensuring stable, precise, and efficient operation.

Currently, there are various types of Knife Gate Valves on the market with different materials and origins. The durability and pricing of these products vary. Some are made of stainless steel, providing a higher cost, while others are constructed from materials like cast iron, limited in usage in environments prone to oxidation, such as saltwater or chemical environments. Additionally, Knife Gate Valves can be made from copper, steel, among other materials, suitable for different conditions.

At AQUA MINA, we specialize in supplying a range of Knife Gate Valves with a simple design and achieving various sizes.

Many sizes of Knife Gate Valves are processed to meet customer demands.

3. Outstanding Advantages of Φ200mm Knife Gate Valve at AQUA MINA?

- Unique design and creative material combination to optimize the product's functionality and increase its durability 2-3 times compared to conventional valves.

- Occupies minimal space during installation.

- Reduced weight and production costs, preventing leakage and offering smoother operation compared to ball or butterfly valves.

- The body of the Φ200mm Knife Gate Valve is made of 40mm thick HDPE. Extremely durable with a lifespan of up to 20 years. HDPE is a material capable of withstanding most weather and chemical impacts, applicable in diverse environments. This ensures widespread use of the Φ200mm Knife Gate Valve.

- The handle of the Φ200mm Knife Gate Valve is made of 2mm thick 40x40mm stainless steel, sturdy and resistant to rust or breakage during usage. The design includes two valve handles for added robustness, allowing customers to integrate with other automatic valve pull systems for optimal product operation.

- The valve disc of the Φ200mm Knife Gate Valve is made of 4mm thick Inox 304, extremely sturdy, preventing corrosion in saltwater environments.

- 100% optimization of water flow through the Φ200mm Knife Gate Valve. With a specially designed transparent valve interior, the valve achieves 100% optimization of water flow. This is a superior advantage of the Knife Gate Valve compared to ordinary PVC ball valves, providing 30% more water flow compared to other PVC ball valve types.

4. Why Should You Choose AQUA MINA's Knife Gate Valve?

Product cost is more than 50% cheaper than imported products.
The product is offered with the best warranty on the current market, up to 24 months.
Easy repair and warranty services provided at AQUA MINA Company.
A reputable manufacturing unit in Vietnam and export in the field of aquaculture equipment.
The product has been exported to many countries worldwide.

In 2023, AQUA MINA was honored to receive the award at Vietstock 2023 for Best Aquaculture Equipment Manufacturer. We commit to providing customers with high-quality products, competitive prices, and the best warranty and maintenance services available today.

We are a unit specializing in providing wholesale Shrimp farming equipment - Aquaculture round tanks - Mobile water tanks - HDPE tarpaulins for ponds and Ponds consulting on the design of high-tech shrimp farms according to customer requirements.

Contact information: AQUA MINA Company Limited

Address: 685 1A Highway, Binh Hung Hoa ward, Binh Tan district, HCM City.
Hotline: 1800 6071 (Toll-free)
Email: sales@aquamina.com.vn
Website: www.thietbinuoitomgiasi.com / www.aouongdidong.com / www.aquamina.com.vn / www.ventek.com.vn

We work for Your SUCCESS!
